ALFA WiFi Camp-Pro 2 WLAN Range Extender Kit

Extend WiFi hotspot signal to multiple devices (Range Extender Package) for boats, yachts, caravans ALFA Camp Pro 2+

The Best Affordable Solution to Turn Public WiFi into a Wifi Internet Hotspot
WiFi Camp Pro 2 is the solution to extend the WiFi hotspot signal and share to multiple devices.

Designed to pick up a weak WiFi signal and repeat as well as amplify it as your own personal hotspot. This is ideal for use during camping or in boats, motorhomes and campers. The Best Affordable Solution to Turn Public WiFi into a Wifi Internet Hotspot

The Best Affordable Solution to Turn Public WiFi into a Wifi Internet Hotspot
It is the reliable and wide coverage for motorhome travelers, marine access to the internet.
Wifi CAMP-PRO is the long-range wireless 802.11b/g/n indoor/outdoor solution for boats/campers/buses, etc.
Wifi CAMP-PRO allows users to launch wireless IEEE 802.11n network at 300Mbps in the frequency of 2.4GHz .
ALFA Network CampPro2 kit includes:

R36A 802.11n router
Tube-U(N) 802.11b/g/n Outdoor USB AP/CPE with N Connector
AOA-2409TF 2.4 GHz, 9 dBi outdoor directional antenna and appropriate accessories.
The R36A router offers fast data rates of up to 300Mbps and is compatible with 802.11b/g devices. The firewall with SPI protects the internal host from hacker attacks. The security features are extensive and include WPA / WPA2 PSK.

ALFA Tube-U(N) is a USB CPE/access point/router for outdoor use with high performance and long range. It supports IEEE 802.11b/g/n WLAN standard with 150Mbit/s in the 2.4GHz frequency range. It is also compatible with the IEEE 802.11b / g / n standard with 150 Mbps. Installation is very simple thanks to the USB connection to PC or laptop. In addition, the supplied software can be used to identify and manage networks in a very simple and understandable way. All current security encryptions are supported.
AOA-2409TF 2.4GHz, 9dBi outdoor radiant antenna was specially developed for the 2.4GHz tube series from ALFA.

Scope of delivery:
R36A 802.11n router
5 dBi antenna for R36A
Tube-U(N) 802.11b/g/n Outdoor USB AP/CPE with N connector
5m USB Cable for Tube-U (N)
AOA-2409TF 2.4GHz, 9dBi Outdoor Radiant Antenna
Power supply unit 230 V to 12 V.
Power supply for cigarette lighter adapter
Installation instructions

Specifications:

Indoor WiFi Device:
Wi-Fi Standard:
IEEE802.11n
IEEE802.11g
IEEE802.11b
Frequency: 2.142 GHz - 2.472 GHz
Channel-Width: 20/40 MHz
Data Rate:

802.11b: up to 11 Mbps
802.11g: up to 54 Mbps
802.11n: up to 300 Mbps
Antenna: 1x internal, 1x external
LED Indicators: Power, LAN, WAN, WLAN, USB
Power Requirement: 12V DC
Security:

WEP 64/128 bit
WPA-PSK
WPA-EAP (PEAP/TTLS)
WPA2-PSK
WPA2-EAP
WPA Mixed 802.1x authentication
Operation Temperature: -20°C~40°C
Storage Humidity: 10%~90% (Non-conensing)
Dimension (mm): 93 x 70 x 26 mm
Weight: 74g

Outdoor WiFi USB Device:

Wi-Fi Standard:
IEEE802.11n
IEEE802.11g
IEEE802.11b
Frequency: 2.142 GHz - 2.472 GHz
Channel Width: 20/40 MHz
Antenna Connector: N male
Interface: USB Type-A
LED Indicator: Power / Connection
Power Required: 5VDC ± 5%
Outdoor Antenna:

Frequency: 2400 MHz - 2500 MHz
Gain: 9 dBi
Impedance: 50Ω
VSWR: 2.0 : 1
Radiation: Omni
Connector: N female
Material: Fiber ice cream
Length: 460 mm
Indoor Antenna:

Frequency: 2400 MHz - 2500 MHz
Gain: 5 dBi
Impedance: 50Ω
VSWR: 2.0 : 1
Radiation: Omni
Connector: RP-SMA female
Material: Rubber
Length: 171.5 mm
